HUG 408MAGSTROKERMIDB MID COMP BALANCED ROTATING ASSEMBLY MID COMPRESSION RATIO, CAST CRANK, I BEAM RODS, KB HYPER PISTONS $1476.00

$200 of of our normal price!
This is our mid compression stroker kit for the 360 block using the Keith Black Hypereutectic Piston and Cast Crankshaft. Magnum blocks tend to have a slightly shorter deck height than the older "LA" style blocks. This particular piston has a 1.465" compression height and may come out of a Magnum block just slightly. If this happens on your application we suggest using a thicker head gasket to make up the difference.
This kit includes:
SCAT 9-360-4000-6123-2125 Cast Crankshaft
SCAT 2-ICR6123-2124-7/16 (I-Beam rods)
Keith Black Hypereutectic Pistons #2026+030 (4.030")
Ring Set Sealed Power 2114+030 (5/64-5/64-3/16")
Rod Bearings #4101HN Clevite "H" series
Main Bearings #4017 Clevite "H" Series (Wide Flange 74-03 blocks)
Precision Race Balancing by Hughes Engines, inc.
Price does not include any heavy metal. This is added as needed on a case by case basis.
Technical Specifications:
Compression Ratios:
| Head Chamber Size (Most Iron) |
64cc |
| Piston Volume (2026) |
-25cc |
| Compressed Gasket Thickness (3106) |
.054" |
| Gasket Bore Diameter (3106) |
4.172" |
| Deck Height |
0 |
| Calculated Compression |
9.3:1 |
| Head Chamber Size (Most Aluminum) |
58cc |
| Piston Volume (2026) |
-25cc |
| Compressed Gasket Thickness (1008) |
.039" |
| Gasket Bore Diameter (1008) |
4.180" |
| Deck Height |
0 |
| Calculated Compression |
10.1:1 |
|
